Pressure gauge type 111.16
- Production:
- WIKA (Germany)
Designed for gaseous or liquid, not highly viscous and not crystallizing measured media that are not aggressive to copper alloys. Joining on the back side.
- Pressure gauge type 111.16
Description and specifications:
| Parameter | Value |
| Nominal size, mm | 40, 50, 63 |
| Measured range (EN 837-1/5) | 0…0,6 to 0…400 bar |
| Class (EN 837-1/6) | 1,6 / 2,5 |
| Joining | External thread on the back side, НР 40: G1/8B, НР 50, 63: G1/4B |
| Sensing element | Bourdon spring, copper alloy |
| Housing | EN 837-1, black plastic with front flange |
| Execution | EN 837-1, housing with front flange |
| Possible options / features | Connector ring in front, bracket joint, both parts can be equipped according to customer´s request |
| Data sheet | РМ 01.10 |
